M18T Series: Temperature Sensor (M18TIP8Q)

https://www.branom.com/web/image/product.template/52290/image_1920?unique=6e7e21e
(0 review)

Features:

  • M18T Series: Temperature Sensor
  • 8:1 Integrated Lens
  • Output: Analog 4-20 mA
  • PNP Alarm
  • Euro M12 5-pin Quick-Disconnect
  • Analog Current Output Rating: 1 kΩ max @24 V dc, max load resistance = [(Vcc-4 V)/0.02 A] Ω
  • Min Operating Temperature: -20 °C
  • Max Operating Temperature: 70 °C
  • Power Supply: 12-30 VDC
  • Delay at Power-Up: 1500 ms
  • Ingress Protection: IP67
  • Housing Style: Barrel
  • Sensing Mode (Detailed): Diffuse
  • Sensing Mode (General): Proximity
  • Device Type: Sensor
  • Housing Material_: SS
  • Feature: RS-232: No
  • Feature: RS-485: No
  • RS-422: No
  • Feature: IO Link: No
  • Feature: Wireless: No
  • Feature: Quick Disconnect: Yes
  • Quick Disconnect Type: M12
  • Feature: Chemical Resistant: Yes
  • Storage Temp: -25 to 75 °C
  • Number of Pins: 5
  • Adjustments: Push Button; Remote Teach
  • Feature: Timing (Hold/Delay): No
  • Input/Output: Analog
  • Barrel Diameter: 18
  • Min Response Time: 25 ms
  • Analog Resolution/Discrete Repeatability: ± 1% of measurement, or ± 1 °C, whichever is greater
  • Remote Teach and Laser Control Input Impedence: 3 kΩ
  • SSI: No
  • Profibus: No
  • Feature: Remote Teach: Yes
  • Feature: Analog Output(s): 4 to 20 mA
  • Connection Type: Integral QD
  • NEMA / UL: NEMA 6
  • Barrel Thread: M18
  • Feature: Common Ethernet Protocol: No
  • Feature: Pump-In/Pump-Out: No
  • Feature: Health/Marginal Signal Output: Yes
  • Feature: PC Configurable: Yes
  • Indicator Type: LED
  • Warm-Up Time: 5 min
  • Analog Linearity: Greater of ±2 °C (0 to +50 °C) or ±1 °C (+50 to +300 °C) or ±1.0%

$ 562.00 562.0 USD $ 562.00

$ 562.00

Not Available For Sale
