  3. Wika 262.30 Series Dry Safety Pressure Gauge, 2.5" Dial, 0 to 1000 psi, 1/4 NPT Monel Lower Mount
Public Pricelist (v2)
Wika 262.30 Series Dry Safety Pressure Gauge, 2.5" Dial, 0 to 1000 psi, 1/4 NPT Monel Lower Mount
Representative photo. Please check item description for details.

Wika 262.30 Series Dry Safety Pressure Gauge, 2.5" Dial, 0 to 1000 psi, 1/4 NPT Monel Lower Mount

https://www.branom.com/web/image/product.template/194353/image_1920?unique=f069c2d
(0 review)

Features

  • Bourdon Tube Pressure Gauges, Monel Safety Pattern
  • Series EN 837-1
  • Model: 262.30
  • Specifications according to data sheet: PM 02.04
  • Measuring System: Monel
  • Case filling: without
  • Nominal size: 2.5"
  • Measuring range: gauge pressure range
  • Scale range: 0/1000 psi
  • Process Connection: 1/4 NPT
  • Connector location: lower mount
  • Window: Polycarbonate
  • Pointer: adjustable pointer
  • Accuracy Class: +/- 2/1/2% (ASME B40.100 Grade A)
  • Case surface: bare case / polished ring
  • Material pressure element: Measuring System MONEL
  • Pressure Gauge Standard: US-Standard
  • Manufacturer logo: *WIKA®*
  • stop pin on dial: at zero
  • Serial number: with Serial number

$ 382.43 382.43 USD $ 382.43

$ 382.43

Not Available For Sale

    This combination does not exist.

    Contact Us
    Product Datasheets

    Datasheet 1

    Share

    Features

    • Bourdon Tube Pressure Gauges, Monel Safety Pattern
    • Series EN 837-1
    • Model: 262.30
    • Specifications according to data sheet: PM 02.04
    • Measuring System: Monel
    • Case filling: without
    • Nominal size: 2.5"
    • Measuring range: gauge pressure range
    • Scale range: 0/1000 psi
    • Process Connection: 1/4 NPT
    • Connector location: lower mount
    • Window: Polycarbonate
    • Pointer: adjustable pointer
    • Accuracy Class: +/- 2/1/2% (ASME B40.100 Grade A)
    • Case surface: bare case / polished ring
    • Material pressure element: Measuring System MONEL
    • Pressure Gauge Standard: US-Standard
    • Manufacturer logo: *WIKA®*
    • stop pin on dial: at zero
    • Serial number: with Serial number
