Wika A-10 TRANSMITTER, 0...100 PSIG; 1/4 NPT; 0 ... 5 V, 3-wire
Features:
- Material of Wetted Parts: 316L
- Case: 316L
- non-linearity: 0.5% BFSL
- Unit: psi
- Pressure type: gauge
- Pressure range: 0...100 psig
- Process Connection: 1/4 NPT
- Temperature range of medium: 0...+80 °C
- Output signal: 0 ... 5 V, 3-wire
- Power supply: 8...30 V DC
- Electrical Connection: flying lead, IP 67
- Cable Length: 15 ft
- Approvals: cULus
Features:
- Material of Wetted Parts: 316L
- Case: 316L
- non-linearity: 0.5% BFSL
- Unit: psi
- Pressure type: gauge
- Pressure range: 0...100 psig
- Process Connection: 1/4 NPT
- Temperature range of medium: 0...+80 °C
- Output signal: 0 ... 5 V, 3-wire
- Power supply: 8...30 V DC
- Electrical Connection: flying lead, IP 67
- Cable Length: 15 ft
- Approvals: cULus
Specifications
| Process Connection Type | NPT-Male |
| Process Connection Location | Bottom |
| Measurement Minimum | 0 |
| Output Communication Protocol | 0-10 VDC, 3-wire |
