Wika 111.11 Series Dry Compressed Gas Regulator Gauge, 2.5" Dial, 0 to 30 psi, 7/16 - 20 UNF Brass 12 O'Clock Mount, 304SS Nut, 304SS Washer & O-ring, Socket w/Press-in Restrictor, 0.012" Orifice
Applications
- Compressed gas regulators
- Beverage dispensing machines
- Suitable for all media that will not obstruct the pressure system or attack copper alloy parts
Product features
- UL-listed (UL-252a or UL-404)
- SS Z&N coated or gold-painted steel case
- Free of oil and grease
Features
- 111.11 2.5 30PSI 7/16-20UNF 12CLK R
- 111.11 2.5 30PSI 7/16-20UNF Top Mount(12 o'clock)
- WIKA logo on dial;
- Socket Brass nickel plated
- Complete supplied with 304SS nut, 304SS washer and O-ring;
- Socket with press-in restrictor, 0.012" orifice
- Wetted parts material copper alloy
- CASE STAINLESS STEEL CHROME PLATED;
- Twist-lock Polycarbonate window
- Accuracy +/-3/2/3 % of Span
- ASME B40.100, Grade B
- *ASSEMBLED IN USA*
Applications
- Compressed gas regulators
- Beverage dispensing machines
- Suitable for all media that will not obstruct the pressure system or attack copper alloy parts
Product features
- UL-listed (UL-252a or UL-404)
- SS Z&N coated or gold-painted steel case
- Free of oil and grease
Features
- 111.11 2.5 30PSI 7/16-20UNF 12CLK R
- 111.11 2.5 30PSI 7/16-20UNF Top Mount(12 o'clock)
- WIKA logo on dial;
- Socket Brass nickel plated
- Complete supplied with 304SS nut, 304SS washer and O-ring;
- Socket with press-in restrictor, 0.012" orifice
- Wetted parts material copper alloy
- CASE STAINLESS STEEL CHROME PLATED;
- Twist-lock Polycarbonate window
- Accuracy +/-3/2/3 % of Span
- ASME B40.100, Grade B
- *ASSEMBLED IN USA*
Specifications
| Gauge: Brand | Wika |
| Gauge: Type | Dial Indicating Gauge |
| Gauge: Product Unit of Measure | psi / inHg |
| Gauge: Process Connection Location | 12 o'clock |
| Gauge: Case Material | Steel |
| Gauge: Wetted Material | Copper Alloy (Brass) |
| Gauge: Fill Type | Dry |
| Gauge: Dial Size | 2-1/2 in (63 mm & 68 mm) |
| Gauge: Process Connection Size | 7/16 - 20 UNF |
| Gauge: Accuracy | ±3% |
| Gauge: Measuring Principle | Bourdon Tube |
| Gauge: Pressure Type | Gauge Pressure |
| Gauge: Model | 111.11 |
| Gauge: Scale Range | ≥ 10 psi (0.6 bar) to ≤ 15,000 psi (1,000 bar) |
