Wika 233.34 Series Glycerin Filled Process Gauge, 4.5" Dial, 0 to 300 psi (ftH2O), 1/2 NPT SS Lower Mount
Applications
- For applications with high dynamic pressure pulsations or vibration a liquid filled case and socket restrictor are available
- Suitable for corrosive environments and gaseous or liquid media that will not obstruct the pressure system
- Process industry: chemical/petrochemical, power stations, mining, on and offshore, environmental technology, mechanical engineering and plant construction
Product Features
- Excellent load-cycle stability and shock resistance
- Solid front thermoplastic case
- Positive pressure ranges to 30,000 psi (2,000 bar)
- All lower mount connection gauges are factory prepared for case filling
Features
- 233.34.4.5" 300 psi FTH2O 1/2 NPT lower mount
- Measuring System 316L
- Ingress Protection: IP 65
- +/- .5% (ASME B40.1 2A)
- Window: laminated safety glass
- adjustable pointer
- Case filling fluid: Glycerine
- Restrictor: stainless steel, D 0.6
- Pressure Gauge Standard: US-Standard
- 2nd scale red
- stop-pin at 6 o'clock
- *WIKA®* Serial number *...*
- *316 SS Tube and Connection*
- Label: WIKA standard without / with Tag-number
Applications
- For applications with high dynamic pressure pulsations or vibration a liquid filled case and socket restrictor are available
- Suitable for corrosive environments and gaseous or liquid media that will not obstruct the pressure system
- Process industry: chemical/petrochemical, power stations, mining, on and offshore, environmental technology, mechanical engineering and plant construction
Product Features
- Excellent load-cycle stability and shock resistance
- Solid front thermoplastic case
- Positive pressure ranges to 30,000 psi (2,000 bar)
- All lower mount connection gauges are factory prepared for case filling
Features
- 233.34.4.5" 300 psi FTH2O 1/2 NPT lower mount
- Measuring System 316L
- Ingress Protection: IP 65
- +/- .5% (ASME B40.1 2A)
- Window: laminated safety glass
- adjustable pointer
- Case filling fluid: Glycerine
- Restrictor: stainless steel, D 0.6
- Pressure Gauge Standard: US-Standard
- 2nd scale red
- stop-pin at 6 o'clock
- *WIKA®* Serial number *...*
- *316 SS Tube and Connection*
- Label: WIKA standard without / with Tag-number
Specifications
| Gauge: Brand | Wika |
| Gauge: Type | Dial Indicating Gauge |
| Gauge: Product Unit of Measure | psi |
| Gauge: 2nd Scale | ftH2O |
| Gauge: Process Connection Location | Lower Mount |
| Gauge: Ingress Protection | IP 65 |
| Gauge: Case Material | Plastic |
| Gauge: Wetted Material | Stainless Steel |
| Gauge: Fill Type | Liquid Filled / Fillable |
| Gauge: Dial Size | 4-1/2 in (110 & 115 mm) |
| Gauge: Process Connection Size | 1/2 NPT |
| Gauge: Accuracy | ±0.5% |
| Gauge: Measuring Principle | Bourdon Tube |
| Gauge: Pressure Type | Gauge Pressure |
| Gauge: Model | 233.34 |
| Gauge: Scale Range | ≥ 10 psi (0.6 bar) to ≤ 15,000 psi (1,000 bar) |
