Representative photo. Please check item description for details.
Wika 213.53 Series 4" Industrial Brass Pressure Gauge, 0 to 100 psi, 1/4" NPT M4 tapped, LM, Silicone Oil Filled
Applications
- Intended for adverse service conditions where pulsating or vibration exists (with liquid filling).
- Hydraulics and compressors
- Suitable for gaseous or liquid media that will not obstruct the pressure system.
Product features
- NEW FlexWindow option available on 2-1/2” gauges
- Vibration and shock resistant (with liquid filling)
- Stainless steel case
- Pressure ranges up to 15,000 psi (1,000 bar)
Specific Features
- Bourdon tube pressure gauge, case filling
- Model: 213.53-E
- Specifications according to data sheet: APM 21X.53 (APM 02.12)
- Measuring system: Copper alloy
- Case: 304 stainless steel with non-removable crimp ring
- Nominal size: 4"
- Scale range: 0/100 psi
- 2nd scale / special scale: kPa
- Process connection: 1/4" NPT M4 tapped
- Connector location: Lower mount
- Mounting flange/bracket: Rear flange, stainless steel
- Restrictor: M4 thread restrictor
- Accuracy class: +/- 1% (ASME B40.100 Grade 1A)
- Case filling fluid: Silicone oil, 350 cSt
- Pressure gauge standard: US-standard
- Color for 2nd scale (inside): Red
- Manufacturer logo: WIKA®
- Serial number on dial: Serial number ...
Applications
- Intended for adverse service conditions where pulsating or vibration exists (with liquid filling).
- Hydraulics and compressors
- Suitable for gaseous or liquid media that will not obstruct the pressure system.
Product features
- NEW FlexWindow option available on 2-1/2” gauges
- Vibration and shock resistant (with liquid filling)
- Stainless steel case
- Pressure ranges up to 15,000 psi (1,000 bar)
Specific Features
- Bourdon tube pressure gauge, case filling
- Model: 213.53-E
- Specifications according to data sheet: APM 21X.53 (APM 02.12)
- Measuring system: Copper alloy
- Case: 304 stainless steel with non-removable crimp ring
- Nominal size: 4"
- Scale range: 0/100 psi
- 2nd scale / special scale: kPa
- Process connection: 1/4" NPT M4 tapped
- Connector location: Lower mount
- Mounting flange/bracket: Rear flange, stainless steel
- Restrictor: M4 thread restrictor
- Accuracy class: +/- 1% (ASME B40.100 Grade 1A)
- Case filling fluid: Silicone oil, 350 cSt
- Pressure gauge standard: US-standard
- Color for 2nd scale (inside): Red
- Manufacturer logo: WIKA®
- Serial number on dial: Serial number ...
Specifications
| Gauge: Brand | Wika |
| Gauge: Type | Dial Indicating Gauge |
| Gauge: Product Unit of Measure | psi |
| Gauge: 2nd Scale | kPa |
| Gauge: Process Connection Location | Panel Mount |
| Gauge: Ingress Protection | IP 66 |
| Gauge: Case Material | Stainless Steel |
| Gauge: Wetted Material | Copper Alloy (Brass) |
| Gauge: Fill Type | Liquid Filled / Fillable |
| Gauge: Dial Size | 4 in (100 mm) |
| Gauge: Process Connection Size | 1/4 NPT |
| Gauge: Accuracy | ±1% |
| Gauge: Measuring Principle | Bourdon Tube |
| Gauge: Pressure Type | Gauge Pressure |
| Gauge: Model | 213.53 |
| Gauge: Scale Range | ≥ 10 psi (0.6 bar) to ≤ 15,000 psi (1,000 bar) |
