Representative photo. Please check item description for details.
Wika 213.53 Series Glycerin Filled Industrial Pressure Gauge, 2.5" Dial, 0 to 6000 psi, 7/16-20 UNF Brass Lower Mount
Applications
- Intended for adverse service conditions where pulsating or vibration exists (with liquid filling).
- Hydraulics and compressors
- Suitable for gaseous or liquid media that will not obstruct the pressure system.
Product features
- NEW FlexWindow option available on 2-1/2” gauges
- Vibration and shock resistant (with liquid filling)
- Stainless steel case
- Pressure ranges up to 15,000 psi (1,000 bar)
Features
- Bourdon tube pressure gauge, stainless steel case
- Model: 213.53
- Specifications according to data sheet: APM 21X.53 (APM 02.12)
- Measuring system: Copper alloy
- Case: 304 stainless steel with non-removable crimp ring
- Nominal size: 2.5"
- Scale range: 0/6000 psi
- 2nd scale / special scale: 2nd scale bar
- Process connection: 7/16-20 UNF SAE #4 J1926 male
- Connector location: Lower mount
- Accuracy class: +/- 2/1/2% (ASME B40.100 Grade A)
- Case filling fluid: Glycerine
- Pointer: Aluminum, black
- Window: Plastic, clear
- Packing: Single packing
- Dial description:
- Pressure gauge standard: US-Standard
- Color for 1st scale (outside): Black
- Color for 2nd scale (inside): Red
- Dial background: White
- Manufacturer logo: WIKA®
- Stop pin on dial: At zero
Applications
- Intended for adverse service conditions where pulsating or vibration exists (with liquid filling).
- Hydraulics and compressors
- Suitable for gaseous or liquid media that will not obstruct the pressure system.
Product features
- NEW FlexWindow option available on 2-1/2” gauges
- Vibration and shock resistant (with liquid filling)
- Stainless steel case
- Pressure ranges up to 15,000 psi (1,000 bar)
Features
- Bourdon tube pressure gauge, stainless steel case
- Model: 213.53
- Specifications according to data sheet: APM 21X.53 (APM 02.12)
- Measuring system: Copper alloy
- Case: 304 stainless steel with non-removable crimp ring
- Nominal size: 2.5"
- Scale range: 0/6000 psi
- 2nd scale / special scale: 2nd scale bar
- Process connection: 7/16-20 UNF SAE #4 J1926 male
- Connector location: Lower mount
- Accuracy class: +/- 2/1/2% (ASME B40.100 Grade A)
- Case filling fluid: Glycerine
- Pointer: Aluminum, black
- Window: Plastic, clear
- Packing: Single packing
- Dial description:
- Pressure gauge standard: US-Standard
- Color for 1st scale (outside): Black
- Color for 2nd scale (inside): Red
- Dial background: White
- Manufacturer logo: WIKA®
- Stop pin on dial: At zero
Specifications
| Gauge: Brand | Wika |
| Gauge: Type | Dial Indicating Gauge |
| Gauge: Product Unit of Measure | psi |
| Gauge: 2nd Scale | bar |
| Gauge: Process Connection Location | Lower Mount |
| Gauge: Ingress Protection | IP 66 |
| Gauge: Case Material | Stainless Steel |
| Gauge: Wetted Material | Copper Alloy (Brass) |
| Gauge: Fill Type | Liquid Filled / Fillable |
| Gauge: Dial Size | 2-1/2 in (63 mm & 68 mm) |
| Gauge: Process Connection Size | 7/16 - 20 UNF |
| Gauge: Accuracy | ±2% |
| Gauge: Measuring Principle | Bourdon Tube |
| Gauge: Pressure Type | Gauge Pressure |
| Gauge: Model | 213.53 |
| Gauge: Scale Range | ≥ 10 psi (0.6 bar) to ≤ 15,000 psi (1,000 bar) |
