Description
Details
- MI Sensor Style AF Style
- Sheath Outside Diameter [in] G - .125 Inch
- Sheath Outside Diameter [in] G - .125 INCH
- Junction Type U - Single Ungrounded
- Junction Type U - Single Ungrounded
- Sheath Material Q - Alloy 600
- Calibraton Type Type K
- Limits of Error Standard Limits
- Mounting Options J - Non-Adjustable Brass 1/8" NPT
- Mounting Options J - Non-Adjustable Brass 1/8" NPT
- Bend Option Straight Length
- Sheath Length [in] 6.000
- Lead Wire Construction J - Fiberglass SS Overbraid, Solid
- Lead Wire Length [in] 36
- Lead Wire Termination F - Miniature Male Plug
- Cold End Seal/Potting 300°F Epoxy
- Transition Style AF - 1/4" with Spring (700), Crimped
- Gauge Size 24 Gauge
- Connector Type F - Miniature Male Plug
- Mating Connector (Y/N) No
- Mating Connector (Y/N) No
- Calibrate/Cert Type No Certification Required
- MI Cable Material Cert (Y/N) No
- Lot Control NA - None
Specifications
| Measurement Maximum | 0 |
| Stem Length | 6 in (152.4 mm) |
| Measurement Minimum | 0 |
