Description
Details
- MI Sensor Style AF Style
- Sheath Outside Diameter [in] J - .250 Inch
- Sheath Outside Diameter [in] J - .250 INCH
- Junction Type U - Single Ungrounded
- Junction Type U - Single Ungrounded
- Sheath Material Q - Alloy 600
- Calibraton Type Type J
- Limits of Error Standard Limits
- Mounting Options None
- Mounting Options None
- Bend Option Straight Length
- Sheath Length [in] 4.000
- Lead Wire Construction J - Fiberglass SS Overbraid, Solid
- Lead Wire Length [in] 72
- Lead Wire Termination T - Standard Split Leads
- Cold End Seal/Potting 1000°F Ceramic
- Transition Style AF5 - 3/8" with Spring (701), Crimped
- Gauge Size 20 Gauge
- Insulated Singles Length [in] 1.500
- Calibrate/Cert Type No Certification Required
- MI Cable Material Cert (Y/N) No
- Lot Control NA - None
Specifications
| Measurement Maximum | 0 |
| Measurement Minimum | 0 |
