[26E3B0E] Warrick 26 Series Low Water Cut Off Control, 100k Sensitivity, Direct Mode, 24 VAC, 1/8" Panel, 1 Form C Relay, Spade Connections, Power Outage Feature, No Enclosure (26E3B0E)

Setra Systems LLC (dba Gems Sensors)

Warrick 26 Series Low Water Cut Off Control, 100k Sensitivity, Direct Mode, 24 VAC, 1/8" Panel, 1 Form C Relay, Spade Connections, Power Outage Feature, No Enclosure (26E3B0E)
26E3B0E

$ 310.30

MADE TO ORDER

[26D3B0E] Warrick 26 Series Low Water Cut Off Control, 50k Sensitivity, Direct Mode, 24 VAC, 1/8" Panel, 1 Form C Relay, Spade Connections, Power Outage Feature, No Enclosure (26D3B0E)

Setra Systems LLC (dba Gems Sensors)

Warrick 26 Series Low Water Cut Off Control, 50k Sensitivity, Direct Mode, 24 VAC, 1/8" Panel, 1 Form C Relay, Spade Connections, Power Outage Feature, No Enclosure (26D3B0E)
26D3B0E

$ 310.30

MADE TO ORDER

[CD2H-M18SS] Barksdale CD2H Diapgragm Pressure Switch, Dual Setpoint, 10 amps @ 125/250 VAC; 3 amps @ 480 VAC; 0.5 amps @ 125 VDC; 0.25 amps @ 250 VDC, .4-18PSI

Barksdale Inc Dba Dynalco Controls Corp

Barksdale CD2H Diapgragm Pressure Switch, Dual Setpoint, 10 amps @ 125/250 VAC; 3 amps @ 480 VAC; 0.5 amps @ 125 VDC; 0.25 amps @ 250 VDC, .4-18PSI
CD2H-M18SS

$ 678.29

MADE TO ORDER
