3 WIRE 100 OHM RTD
1/2" X 1/2" 316SS THERMOWELL, STEPPED, 3
6" OVERALL LENGTH (4.5" INSERTION)
1/2" 316SS NIPPLE
ALUMINUM HEAD WITH 3/4" CONDUIT
Specifications
| RTD: Brand | Pyromation, Pyromation |
| RTD: Accuracy | Grade B, Grade B |
| RTD: Circuit Type | Single 3-Wire, Single 3-Wire |
| RTD: Connection Size | 1/2 NPT, 1/2 NPT |
| RTD: Connection Type | Hex Nipple, Hex Nipple, Spring-Loaded, Spring-Loaded |
| RTD: Output | Pl100 Ω, Pl100 Ω |
| RTD: Length (Probe/Sheath/TW) | 16 in, 16 in |
| RTD: Stem Diameter | 1/4 in, 1/4 in |
| RTD: Wetted Material | SS, SS |
| RTD: Enclosure Rating | NEMA 4X, NEMA 4X |
| RTD: Has Thermowell | No, No |
| RTD: Cover / Head Material | Cast Iron, Cast Iron |
| RTD: Min Temp | -328 °F, -328 °F |
| RTD: Max Temp | 1112 °F, 1112 °F |
