S18 DAYLIGHT VISIBLE EZ Light - 18 mm - IP67 (S18DLRXXPT)

https://www.branom.com/web/image/product.template/20221/image_1920?unique=df497b9
(0 review)

Features:

  • S18 DAYLIGHT VISIBLE EZ Light
  • 18 mm
  • IP67
  • Single Color: Red
  • 10-30 V dc PNP Input
  • 4 Screw Terminal Wiring
    • Power: DC
  • Feature: Display Lighting: No
  • Max Current Color: 25 mA
  • Power Source: VDC
  • Ingress Protection: IP67/69
  • Housing Style: Barrel Mount - Flat Window
  • Feature: Washdown Rated: Yes
  • Feature: IO Link: No
  • Physical Dimensions: 23.5 x 34.6 mm
  • Feature: Indication: Yes
  • Supply Voltage: 10-30 VDC
  • Feature: Quick Disconnect: No
  • Color Technology: Standard LED
  • Feature: Audible: No
  • Color 1 - Wavelength/Color Temp/Coordinates: 625 nm
  • Housing Color: Black
  • Color Input Control: Individual (One wire/color, same number of colors as input wires)
  • Multi-Color Device: Single Color On
  • Number of Colors / Segments: 1
  • Product Size (mm): 18 mm
  • Max Input Response Time (ms): 1 ms
  • Feature: Chemical Resistant: No
  • Indication Intensity: High Brightness & Daylight Visible
  • NEMA / UL: NEMA/UL 4X/13
  • Cord/Cable Length: 2 m
  • Max Input Response Time: 1 ms

$ 56.00 56.0 USD $ 56.00

$ 56.00

Not Available For Sale

    This combination does not exist.
