[50019709] Wika 233.53 Series Glycerin Filled Pressure Gauge, 2.5" Dial, -1 to 11 bar (inHg/psi/°F) Ammonia Scale, 1/4 NPT SS Lower Mount

Wika Instrument Lp

Wika 233.53 Series Glycerin Filled Pressure Gauge, 2.5" Dial, -1 to 11 bar (inHg/psi/°F) Ammonia Scale, 1/4 NPT SS Lower Mount
50019709

$ 112.67

On Hand: 4

[4302052] Wika 111.12 Series Dry Pressure Gauge, 2" Dial, 0 to 160 psi, 1/4 NPT Brass Center Back Mount, Pressure Vent

Wika Instrument Lp

Wika 111.12 Series Dry Pressure Gauge, 2" Dial, 0 to 160 psi, 1/4 NPT Brass Center Back Mount, Pressure Vent
4302052

$ 28.54

On Hand: 4

[804489] Banner Cordset: Double-Ended M12; 5-pin Straight Male; 5-pin Straight Female; 4.58 m 5x22 Shielded Black PVC Jacket; Nickel-Plated Brass Coupling Nuts (MQDEC3-515SS)

Banner Engineering Corp

Banner Cordset: Double-Ended M12; 5-pin Straight Male; 5-pin Straight Female; 4.58 m 5x22 Shielded Black PVC Jacket; Nickel-Plated Brass Coupling Nuts (MQDEC3-515SS)
804489

$ 74.00

On Hand: 4

[802640] Banner T18-2 Series: Diffuse Reflective with Pot; Range: 750 mm; Input: 10-30 V dc; Outputs: Complementary PNP; 4-pin M12 Integral QD (T18-2VPDL-Q8)

Banner Engineering Corp

Banner T18-2 Series: Diffuse Reflective with Pot; Range: 750 mm; Input: 10-30 V dc; Outputs: Complementary PNP; 4-pin M12 Integral QD (T18-2VPDL-Q8)
802640

$ 95.00

On Hand: 4

[79995] Banner T30UX Series w/ Discrete Output; Range: 100 mm - 1 m; Input: 10-30 V dc; Output: NPN PNP NO NC selectable; 4-pin M12 Integral QD (T30UXDAQ8)

Banner Engineering Corp

Banner T30UX Series w/ Discrete Output; Range: 100 mm - 1 m; Input: 10-30 V dc; Output: NPN PNP NO NC selectable; 4-pin M12 Integral QD (T30UXDAQ8)
79995

$ 428.00

On Hand: 4

[70381] Banner WORLD-BEAM QS30 Series: Adjustable-Field; Range: 50 to 300 mm; Input: 10-30 V dc; Output: Bipolar: 1 NPN; 1 PNP; 5-pin M12 Integral QD (QS30AFQ)

Banner Engineering Corp

Banner WORLD-BEAM QS30 Series: Adjustable-Field; Range: 50 to 300 mm; Input: 10-30 V dc; Output: Bipolar: 1 NPN; 1 PNP; 5-pin M12 Integral QD (QS30AFQ)
70381

$ 224.00

MADE TO ORDER

[34341] Banner EZ-BEAM Q40 Series: Fixed Field; Range: 600 mm; Input: 20-250 V ac; Output: SPST Solid-state Light Operate; 4-pin Micro Integral QD (Q40AW3FF600Q1)

Banner Engineering Corp

Banner EZ-BEAM Q40 Series: Fixed Field; Range: 600 mm; Input: 20-250 V ac; Output: SPST Solid-state Light Operate; 4-pin Micro Integral QD (Q40AW3FF600Q1)
34341

$ 219.00

On Hand: 4
