Point Level Instrumentation

Point level sensors measure preset levels of liquid, slurry, or solid media and open or close an electrical contact at the desired setpoint. When the media reaches the specified level, the output transmitted by the point level switch triggers an alarm or display. In some applications, the sensors are also used to trigger pumps, valves, or other controls to return the media to the preset level.

Install point level switches horizontally or vertically based on your application or use the devices with multiple sensors to provide multi-stage point level measurement.  Point level instrumentation is versatile enough for use across a broad range of applications, including monitoring levels in:

  • Storage Silos

  • Containers

  • Vessels

  • Holding Ponds

  • Natural Bodies of Water

Point Level Measurement Sensors Provide Reliable Overflow Prevention

For applications that require simple, level control or alarms, Branom Instrument Co. stocks point level switches from some of the industry’s most trusted manufacturers. We offer floats, paddle switches, capacitance probes, vibrating tuning forks and more that can be used in conjunction with controls or alarms to prevent overflows and runouts in vessels of all sizes.

Capacitance Probe Switches

Capacitance probe switches are rod-shaped sensors that provide point level measurement of liquids, slurries, and pastes. Once installed, the sensors and vessel serve as the two electrodes that form a capacitor, and the media inside the vessel represents the dielectric. The radio frequency signals produced by the capacitance point level switch calculate changes in current and transmit them as an output signal.

Most capacitance point level switches are made of stainless steel and can withstand high temperatures and corrosive environments, making them ideal for use in chemical applications. Branom offers capacitance probe switches in several options from KROHNE and Gems.

Mechanical Floats

Mechanical float switches are mechanically actuated float sensors used for point level measurement of corrosive and non-corrosive liquids and slurries. When fluid levels rise to a specified level, the mechanical float switch may automatically trigger a pump or valve that remains on until the fluid returns to the desired level.

The sensors are often installed at two different levels to prevent overflow in the event the first pump fails. Mechanical float switches are commonly used for point level measurement of water and wastewater. Our inventory includes corrosion-resistant mechanical floats from Gems and Dwyer.

Single & Multi-Point Level Switches

Single point level float switches detect the level of a single liquid contained in a tank or vessel. These switches are horizontally or vertically mounted and actuate once the fluid reaches a certain level.

Use single point level switches in applications where you only need to monitor one fluid level. Multi-point float level switches allow you to track and measure multiple fluid points within the same tank or vessel. You can also use multi-point switches to simultaneously measure two or more liquids with different specific gravities contained in the same tank, or for differential level control. We offer low maintenance point level switches from GemsDwyer, and Flowline.

Rotating Paddle Switches

Rotary paddle switches are constructed of a low-speed motor with a paddle wheel and are used for point level measurement of dry bulk solids. They can be installed horizontally, vertically, or at the base of a vessel and can be used for single or multi-point level measurement.

The rotary paddle switch unit operates using a self-powered motor and shaft that causes the paddle to rotate continuously. When a solid material contacts the paddle, it causes it to stop moving, triggering the sensor to indicate a specific level was reached. As the silo or vessel empties, the paddle begins rotating again.

This type of point level switch is best for use with pelletized, granular, and powdered media. Our inventory includes rotating paddle switches from Bindicator, Dwyer, and UWT.

Vibrating Tuning Fork Switches

Vibrating tuning fork switches are point level switches designed based on the vibrating tuning fork principle. These instruments take point level measurement of solids and liquids and can be used in high static bulk powder environments.

To provide point level measurement readings, the vibrating tuning fork level switch is positioned inside a tank at a specified level. Voltage is then applied to the tuning fork to create a frequency that produces oscillations of the fork. The frequency then changes when the vibrating tuning fork contacts a liquid or solid. These changes are read by the sensor and converted into switching signals that trigger a high- or low-level alarm, display or control.

Branom provides vibrating tuning fork switches from KROHNEDwyer, and Bindicator.

Request a Quote for Point Level Switches and Accessories

We maintain a huge, in-stock inventory and offer startup, calibration, and other technical services or all our point level control and monitoring equipment. Contact us today to learn more about point level measurement solutions.

Gems Sensors - Corporate
GEMS LS-1900 LEVEL SWITCH, BUNA N FLOAT, 316 SS STEM & MOUNTING, 150PSI MAX PRESSURE, SPST SWITCH, 20VA

01907

118.00 118.00 118.0 USD
On Hand: 3
Platt Electric Supply - Corporate
ABB Liquid Level Monitoring Relay, 24-240VAC/VDC

1SVR730850R0200

162.70 162.70 162.70000000000002 USD
On Hand: 1
Gems Sensors - Corporate
ELECTRODE FITTINGS 5/8" - 18UNF

3B2B

69.00 69.00 69.0 USD
On Hand: 2
Gems Sensors - Corporate
LS-1750 FLOAT SWITCH

01750

114.00 114.00 114.0 USD
On Hand: 8
Mercury Displacement Industries Inc (MDI)
MECHANICAL FLOAT 13 AMP, SPST NORMALLY OPEN, WIDE ANGLE, 20' CABLE

M-RED-20

114.00 114.00 114.0 USD
On Hand: 1
Gems Sensors - Corporate
LS-1700 LEVEL SWITCH,Teflon Float, 316 SS Stem, 1/8" NPT, 24" lead

26791

134.00 134.00 134.0 USD
On Hand: 0
Gems Sensors - Corporate
LS-7 Series Level Switch,Nylon,Type 5

140620

50.00 50.00 50.0 USD
On Hand: 2
Gems Sensors - Corporate
GEMS LS-750 Sreies Level Switch

149350

162.00 162.00 162.0 USD
On Hand: 1
Venture Measurement Company, Llc
H-36S MOLDED SILICONE FLEXIBLE SHAFT WITH PINS H-36S

LAR110275

53.26 53.26 53.26 USD
On Hand: 0
Mercury Displacement Industries Inc (MDI)
MECHANICAL FLOAT 13AMP,SPST-NORMALLY CLOSED,NARROW ANGLE, 50' CABLE

M-YEL-50

91.00 91.00 91.0 USD
On Hand: 3
Gems Sensors - Corporate
SERIES 26 LOW WATER CUTOFF - STANDARD MOUNT, 6 SEC TIME DELAY(DECREASING) , POWER OUTAGE OPTION

26B1A0E06

196.00 196.00 196.0 USD
On Hand: 2
Gems Sensors - Corporate
SS Float Only, Type 138935

138935

80.00 80.00 80.0 USD
On Hand: 3
Gems Sensors - Corporate
LOW WATER CUTOFF PLUG-IN MODULE, 26K OHM SENSITIVITY 12VAC,11 PIN OCTAL MT, NO ENCLOSURE

26NMC1B0

282.00 282.00 282.0 USD
On Hand: 2
Gems Sensors - Corporate
LS-1800 Series Buna-N Float Switch, 20VA

01801

70.00 70.00 70.0 USD
On Hand: 9
Gems Sensors - Corporate
LEVEL CONTROL 50K OHM SENSITIVITY, 120VAC POWER

16MD1A0

281.00 281.00 281.0 USD
On Hand: 2
Gems Sensors - Corporate
FABRI-LEVEL SWITCH KIT 2”NPT SS FITTINGS AND 2.0625" FLOAT DIAMETER, .75SG

24577

1,114.00 1,114.00 1114.0 USD
On Hand: 1
Gems Sensors - Corporate
LS-2050 Series Side Mount Level/Float Switch, 316SS, SPDT 20VA

30290

444.00 444.00 444.0 USD
On Hand: 1
On Order: 2
Gems Sensors - Corporate
LS-1755 Level Switch, SS Float & Stem, 20VA, 1/8"MNPT, SPST

01755

113.00 113.00 113.0 USD
On Hand: 2
Gems Sensors - Corporate
LS-7 Type 5 Level Switch Float, Polypropylene SPST 20VA

131100

51.00 51.00 51.0 USD
On Hand: 2
Gems Sensors - Corporate
3N Series Probe Holder, 3 Probes, PVC

3N3A

307.00 307.00 307.0 USD
On Hand: 1
